Overview

City Model 1 includes both pedal assist (choose how much help you want using the digital controls) to cruise at up to 28 MPH, as well as a thumb throttle, which can propel you at up to 20 MPH without pedaling. There’s a large, handlebar display showing your speed, distance, time, battery life, and other information, plus a kickstand for easy parking. Includes Kenda puncture-resistant tires, powerful hydraulic disc brakes for safer and stopping, and Shimano’s 7 speed drivetrain.

Top speed:
28 MPH on pedal assist, 20 MPH on throttle

Motor:
Shengyi rear hub motor, 48V, 500W, 50 Nm torque rating

Throttle:
Thumb throttle, left side

Display:
Denago K5242 LCD with speed, motor power, trip distance, odometer, trip time, battery charge level, and walk mode functions

Battery:
48V, 13.6Ah, 652.8Wh, Semi Integrated style with LG cells

Sensors:
Speed, Cadence

Charger:
Multi-voltage 110-240V, 3A Fast Charger with USA plug

FRAME AND FORK

6061-T6 Aluminum Alloy, Top tube style

Kickstand:
included

DRIVETRAIN

Pedals:
Platform, aluminum alloy, 9/16” with reflectors

Crankset:
Aluminum alloy, 170mm, 42 tooth chainring

Bottom Bracket:
Sealed, square taper, 126mm, English thread

Rear Derailleur:
Shimano Tourney, 7 speed

Freewheel:
Shimano Tourney, 7 speed, 14-28 teeth

Shifter:
Shimano Tourney, 7 speed, trigger

Chain:
KMC Z-Series, 3/32”

COCKPIT

Handlebar:
Zoom aluminum alloy, 31.8mm diameter, 660mm long

Handlebar Bell:
included

Grips:
Black rubber, lock-on style

Stem:
Adjustable angle, 31.8mm clamp, 1 ⅛” threadless, 90mm extension

Headset:
1 ⅛”, sealed, threadless

Saddle:
Velo Plush Comfort with lift handle

Seatpost:
Zoom aluminum alloy, 30.4mm diameter, 300mm length

Seatpost Clamp:
Zoom, quick release

BRAKES

Levers:
Zoom HB875 hydraulic disc with motor cut-off

Calipers:
Zoom HB875 hydraulic disc with motor cut-off

Rotors:
180mm, 6 bolt type

WHEELS

Tires:
Kenda Kwick Seven.5, 27.5 x 2.2”, K-Shield puncture protection with safety reflective stripe

Tubes:
Kenda 27.5 x 2.2”, schrader valve

Rims:
Aluminum Alloy, 36 holes, 27.5”

Hubs:
Front - Quando Disc, nutted, 36 holes; Rear Shengyi DGW22, nutted, 36 holes

Spokes:

36 Black ED13 gauge spokes front, 36 12 gauge spokes rear

Nipples:
Brass

WEIGHT AND PAYLOAD

Complete ebike with battery:
53 lbs

Maximum rider weight:
280 lbs

Maximum cargo capacity:
35 lbs on the optional rear rack

WHAT'S IN THE BOX

Complete eBike
Keys
3 Amp fast charger
Quickstart Guide
Front, rear, and wheel reflectors
Lithium-Ion battery
Bell
Owner’s Manual
Assembly tools (pedal wrench, multi-tool)


Overview

City Model 1 includes both pedal assist (choose how much help you want using the digital controls) to cruise at up to 28 MPH, as well as a thumb throttle, which can propel you at up to 20 MPH without pedaling. There’s a large, handlebar display showing your speed, distance, time, battery life, and other information, plus a kickstand for easy parking. Includes Kenda puncture-resistant tires, powerful hydraulic disc brakes for safer and stopping, and Shimano’s 7 speed drivetrain.

Tech Specs

Top speed: 28 MPH on pedal assist, 20 MPH on throttle

Motor: Shengyi rear hub motor, 48V, 500W, 50 Nm torque rating

Throttle: Thumb throttle, left side

Display: Denago K5242 LCD with speed, motor power, trip distance, odometer, trip time, battery charge level, and walk mode functions

Battery: 48V, 13.6Ah, 652.8Wh, Semi Integrated style with LG cells

Sensors: Speed, Cadence

Charger: Multi-voltage 110-240V, 3A Fast Charger with USA plug

FRAME AND FORK

6061-T6 Aluminum Alloy, Top tube style

Kickstand: included

Groupset

DRIVETRAIN

Pedals: Platform, aluminum alloy, 9/16” with reflectors

Crankset:  Aluminum alloy, 170mm, 42 tooth chainring

Bottom Bracket:  Sealed, square taper, 126mm, English thread

Rear Derailleur:  Shimano Tourney, 7 speed

Freewheel: Shimano Tourney, 7 speed, 14-28 teeth

Shifter:  Shimano Tourney, 7 speed, trigger

Chain: KMC Z-Series, 3/32”

COCKPIT

Handlebar: Zoom aluminum alloy, 31.8mm diameter, 660mm long

Handlebar Bell: included

Grips: Black rubber, lock-on style

Stem:  Adjustable angle, 31.8mm clamp, 1 ⅛” threadless, 90mm extension

Headset: 1 ⅛”, sealed, threadless

Saddle: Velo Plush Comfort with lift handle

Seatpost: Zoom aluminum alloy, 30.4mm diameter, 300mm length

Seatpost Clamp: Zoom, quick release

BRAKES

Levers:  Zoom HB875 hydraulic disc with motor cut-off

Calipers: Zoom HB875 hydraulic disc with motor cut-off

Rotors:  180mm, 6 bolt type

WEIGHT AND PAYLOAD

Complete ebike with battery: 53 lbs

Maximum rider weight: 280 lbs

Maximum cargo capacity:  35 lbs on the optional rear rack

WHAT'S IN THE BOX

Complete eBike Keys 3 Amp fast charger Quickstart Guide Front, rear, and wheel reflectors Lithium-Ion battery Bell Owner’s Manual Assembly tools (pedal wrench, multi-tool)

Wheelset

Tires:  Kenda Kwick Seven.5, 27.5 x 2.2”, K-Shield puncture protection with safety reflective stripe

Tubes:  Kenda 27.5 x 2.2”, schrader valve

Rims: Aluminum Alloy, 36 holes, 27.5”

Hubs: Front - Quando Disc, nutted, 36 holes; Rear Shengyi DGW22, nutted, 36 holes

Spokes:

36 Black ED13 gauge spokes front, 36 12 gauge spokes rear

Nipples:  Brass
